Specs
| Tractor PTO HP | 15-50 |
|---|---|
| Tractor Hitch | CAT 1 clevis |
| Cutting Height Range (in) | 1 to 9 |
| Cutting Capacity Diameter (in) | 2 |
| Cutting Width (in) | 48 |
| Blade Tip Speed (fpm) | 13,000 |
| Weight (lbs) | 635 (with chain shield) |
| Deck Thickness (in) | .105 (12 ga) |
| Side Frame Thickness (in) | .135 (10 ga) |
| Side Frame Depth (in) | 10.5 |
| Transport Width (in) | 55 |
| Output Shaft Diameter (in) | 1.57 |
| Gearbox Warranty | 6 year limited |
| Overall Length (in) | 86 |
| Deck Construction | Smooth top, sloped |
| Gearbox HP | 65 *Gearbox horsepower ratings listed are based on field testing. |
| Blade Dimensions (in) | 1/2 x 4 |
| Frame and Deck Support (in) | 3 x 3 full-length structural tubes |
| Tractor PTO Speed (rpm) | 540 |
| Quick-hitch Compatible | Yes |
| Blade Carrier | Oval stump jumper |
| Driveline Protection | Slip-clutch |
| Skid Shoes | Full-length, replaceable |
| Rear Bumper | Z-channel |
| Options | Rubber belting/steel band or chain shielding; check chains |
