Specs
| Tractor PTO HP | 35-90 |
|---|---|
| Tractor Hitch | CAT 1 and 2 clevis |
| Cutting Height Range (in) | 2 – 12 |
| Cutting Capacity Diameter (in) | 2 |
| Cutting Width (in) | 84 |
| Blade Tip Speed (fpm) | 15,086 |
| Weight (lbs) | 1,118 (with chain shield) |
| Deck Thickness (in) | .120 (11 ga) |
| Side Frame Thickness (in) | .135 (10 ga) |
| Side Frame Depth (in) | 11.6 |
| Transport Width (in) | 91.3 |
| Output Shaft Diameter (in) | 1.57 |
| Gearbox Warranty | 6 year limited |
| Overall Length (in) | 124 |
| Deck Construction | Smooth top, sloped |
| Gearbox HP | 90 *Gearbox horsepower ratings listed are based on field testing. |
| Blade Dimensions (in) | 1/2 x 4 |
| Frame and Deck Support (in) | 3 x 3 full-length structural tubes |
| Tractor PTO Speed (rpm) | 540 |
| Quick-hitch Compatible | Yes |
| Blade Carrier | Oval stump jumper |
| Driveline Protection | Slip-clutch |
| Skid Shoes | Full-length, replaceable |
| Rear Bumper | Z-channel |
| Options | Rubber belting/steel band or chain shielding; check chains; dual tailwheel |
