Specs
| Tractor PTO HP |
20-50 |
|---|---|
| Tractor Hitch |
CAT 1 / cantilevered |
| Cutting Height Range (in) |
2 to 9 |
| Cutting Capacity Diameter (in) |
1 |
| Cutting Width (in) |
69 |
| Blade Tip Speed (fpm) |
14,340 |
| Weight (lbs) |
575 |
| Side Frame Depth (in) |
7 |
| Gearbox Warranty |
1 year cutter / 3 years gearbox |
| Blade Dimensions (in) |
.5 x 3 |
| Frame and Deck Support (in) |
3/8 rails |
| Tractor PTO Speed (rpm) |
540 |
| Quick-hitch Compatible |
Yes |
| Blade Carrier |
Oval stump jumper |
| Driveline Protection |
Shear-bolt or slip-clutch |
| Tailwheel (in) |
4 x 16 laminated |
| Options |
Belt standard / chain shielding optional |
| Woods C® |
