Specs
Tractor PTO HP | 30-50 |
---|---|
Hitch Category | CAT 1 and 2 |
Operating Weight; including chute & hydraulic deflector (lbs) | 700 |
Working Width (in) | 84 |
Working Height (in) | 27 1/2 |
Overall Width (in) | 85 1/4 |
Overall Length (in) | 45 1/2 |
Impeller Diameter (in) | 24 |
Impeller Width (in) | 9 |
Impeller (rpm) | 540 |
Main Auger Diameter (in) | 15 |
Auger Driven System | Chain No. 60 |
Auger (rpm) | 200 |
Chute Rotation | Manual or Hydraulic |
Replaceable and Reversible | Yes |
Cutting Edge Dimension (in) | 3/8 x 1 1/2 |
Main Driving System | Driveline Series 50 |
Chain Idler | Yes |
Parking Stand | Yes |
Number of Auger Shear Bolt | 1 (on drive shaft) |
Number of Impeller Shear Bolt | 1 (on driveline) |
Type of Hitch | 3 pts., CAT 1 & 2 |
Quick Hitch Compatible | Yes, CAT 1 only |
Gearbox Warranty | 6-years Includes Seals |
