Specs
Engine
- Engine Brand Kawasaki®
- Engine Model FX Series
- Engine Model Number 691V
- Engine Displacement 726cc
- Engine Output 22HP
- Starter Type Electronic with quick reset
- Fuel Tank Capacity 7.5 gal. US (28.4 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 15 amp regulated
- Fuel Gauge No
- Choke Separate Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Carburetor
Drive System
- Transmission 12cc Hydro-Gear® pumps / 240cc Parker® wheel motors
- Forward Speed 10 mph / 16 km/h
- Reverse Speed 5 mph / 8 km/h
Cutting Deck
- Deck Cutting Width 48 in
- Deck Engagement (PTO) Electric
- Deck Construction 10 ga shell w/ 7 ga top & bottom reinforcement
- Spindle Construction HD 8" aluminum housing, 35mm double-row sealed ball bearings, 1-3/8" through-shaft and maintenance-free design
- Blade(s) 3 17" long high-lift Marbain® blades, 1-1/2" of blade overlap
- Deck Lift Hand lever adjusting spring lift, pin selector for height
- Cutting Height Range 1.5”- 4.5”
- Anti-Scalping 2 front deck gauge wheels
Chassis
- Frame 2" x 3" full-length tube frame
- Front Axle 2" x 3" tube construction
- Front Caster Mount 3/8" thick steel
- Suspension Hand lever adjust, 3-position spring suspension foot platform
Controls
- Cruise Control NA
- Brakes Hand lever control / external band
- Steering Control Lap Bar Steering Wheel Control
Wheels
- Rear Tires 24"x9.5"-12"
- Front Tires 13x5-6" Reliance Run Flat carlisle
Dimensions
- Weight (approx.) 1015 lbs
Additional Specifications
- Hour Meter Crew Boss
- Model Number 53FI8CSFA50
Warranty
- Commercial Warranty 3-Year / No Hour Limit Warranty and/or 5-Year 1,200 Hour
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
- Horsepower *As required by Kawasaki, horsepower tested in accordance with SAE J1995 and rated in accordance with SAE J2723 and certified by SAE International.
