Specs
| Product Tier | Professional |
|---|---|
| Tractor PTO HP | 45-200 |
| Tractor PTO (rpm) | 540 or 1 , 000 |
| Hitch Type | Swivel clevis hitch |
| Adjustable Cutting Height (in) | 2-15 |
| Cutting Capacity Diameter (in) | 3 |
| Cutting Width (ft) | 15 |
| Cutting Area Shielding | Single or Double Chain |
| Blade Tip Speed (fpm) | 15 , 526 (wing) , 15 , 904 (center) at 540 rpm 15 , 708 (wing) , 15 , 422 (center) at 1 , 000 rpm |
| Blade Size (in) | .5 x 4 |
| Blade Overlap (in) | 6 |
| Weight/Tongue Weight (lbs) | 4 , 595/1 , 935 |
| Transport Width (in) | 96 |
| Hydrualics Wing Flex (degrees) | 90 up , 22 down |
| Side Skirt (in) | .25 thick x 13 deep |
| Stump Jumper Type | Oval |
| Deck Thickness (in) | 0.135 |
| Wheel Type | 21 in. laminated; 25 in. severe-duty Ag; 29 in. used aircraft foam-filled options for severe-duty Ag and used aircraft |
| Driveline Rating | CAT 6 CV main , CAT 4 wing |
| Gearbox Rating (hp) | 210 splitter / 200 center and wing |
| Gearbox Warranty (yrs) | 10 |
| Output Shaft Size (in) | 2 dia |
| Options | Double row chain shielding , Dual wheels , Towing Eye |
